Product

Technical data:
Speed: 55~~65 pcs/min
Paper cup top diameter: Min 100mm ~~Max 145mm Paper cup bottom diameter: Min 90mm~~Max 115mm Paper cup height: Min 100mm~~Max 170 mm or customize up to 200MM
Raw material: 180~~350gsm, single or double PE coating paper
General power: 11 Kw Electricity: 380V 3 phases
Air consumption: 0.2 cbm/min
Weight: 2500 KGS



Specification:
1. Paper cup bottom sealing by Leister CERAMIC hot air system, BRAND BANKO.
2. It is specially designed for some tall bowls, which is more then 115mm height and less then 170mm height bucket.
3. Cup side sealing by ultrasonic.
4. Double PE coating paper cups for cold drink as well as hot drink.
5. With our unique original designed bottom knurling system, single shaft, korea type, this ensures the low leaking ratio and high quality of paper cups.
6. Paper sucking system adopt the big air Cylinder, big power,stable running and durable working.
7. With automatic lubricating system, it will automatic lubricating to every moving parts when machine runs.
8. Every cam will be harden to ensure it can run for a long long time.
9. Machine is designed with double turning plate
10. Equipped with automatic cup collecting stacking and counting system.
11. Bottom paper we have a special pre-feeding system, so the bottom paper feeding is “0” waste.
12. Machine designed with Open cam system, more durable working and big power, easy maintenance.
