A. DESCRIPTION
1、Unwinding unit and rewinding unit
• automatic loading and unloading by hydraulic
• Magnetic powder as brake, motor as clutch
2、Auto web guiding
• Splicing table
• Detection mode：edge checking
• Precision：±0.1mm
3、Feeding system
• Rubber rollers for feeding
4、Printing unit 4 units
• Helical gear
• Ceramic anilox roller one set (4 pcs)
• Printing cylinder one set (4 pcs)
• Ceramic anilox roller: LPI depends on buyer
• Printing cylinder: repeat depends on buyer
• Single side doctor blade
• Ink case
• Gear：cp1/8
5、Drying system
• IR
6、Auto stopping function
7、Meter counter
8、Simple plate mounter

B. Technical parameter
1 Max unwinding diameter: 1200mm
2 Printing repeat: 175mm-430mm
3 Max width: 960mm
4 Max printing width: 950mm
5 Power supply: 380V 3PH 50Hz
6 Total power: 30KW
7 Machine speed: 0-80m/min
8 Printing plate thickness: 1.7mm
9 Double glue tap thickness: 0.38mm
10 Printing precision: ±0.15mm
11 Air shaft diameter: 3inches
